MIL-F-80069D
3.3.3 Surfaces. All surfaces shall be clean and free of harmful or
extraneous materials. All edges shall be either rounded or beveled unless
sharpness is required to perform a necessary function. Except as otherwise
specified herein, the condition and finish of all surfaces shall be in
accordance with the manufacturer's commercial practice.
3.3.4 Welding, brazing, or soldering. Welding, brazing, or soldering shall
be employed only where specified in the original design. None of these
operations shall be employed as a repair measure for any defective part.
3.3.5 Painting.
Unless otherwise specified (see 6.2), the machine shall
be painted in accordance with the manufacturer's commercial practice and
color.
3.3.6 Threads. All threaded parts used on the machine and its related
attachments and accessories
shall conform to FED-STD-H28 and the applicable
"Detailed Standard" section referenced therein.
3.3.7 Gears. All gears shall be constructed from a material suitable for
the intended purpose. All drive gears shall have the hardness, surface
finish, and toughness that will enable the gear train to transmit full rated
l torque of the drive motor without gear damage, failure, or premature
deterioration and wear.
3.3.8 Electromagnetic interference control. When specified
(see
6.2),
equipment furnished under
his specification shall comply with MIL-STD-461.
The equipment and subsystem(s) class and the emission - and susceptibility
requirements shall be as specified.
3.4 Components, and specific requirements.
3.4.1 Type I machine. Type I machines shall consist of not less than a
base, spindle assembly, jaw assembly, lubrication system, electrical system,
system,
and the other components required to meet requirements specified herein. When
specified (see 6.2), Type I machines shall be provided with an automatic
sequence of operation control.
3.4.1.1 Base. The machine shall have a base of adequate strength to with-
stand forces applied while the machine is operating at its maximum rated
capacity.
The base shall be a workbench mounted, base cabinet style, or floor
stand style, as specified and fully described (see 6.2). When machine
components are enclosed within the base, base cabinet or floor stand,
removable or hinged panels shall be provided to allow access to these
components for lubrication, adjustment, or maintenance.
l
3.4.1.2 Spindle assembly. The spindle assembly shall consist of spindle
housing, spindle sleeve, spindle bearings, spindle, spindle drive, and spindle
advance mechanism. The spindle shall be mounted on ball or roller bearings,
contained in the spindle sleeve and the spindle sleeve In the spindle housing.
The spindle shall be driven by an electric motor through a belt and pulley
drive. The spindle sleeve shall advance and retract the spindle through a
gear segment and lever arrangement.
