MIL-G-26869D
The inspection requirements specified
4.2 Classification of inspections.
herein are classified as follows:
a, First article inspection (see 4.4).
Quality conformance inspection (see 4.5).
b.
all
4.3 Inspection conditions. Unless otherwise specified (see 6.2),
inspections shall be performed in accordance with the test conditions
specified in 4.7.1.
4.4 First article inspection. When a first article inspection is required,
it shall be applied to the first article submitted in accordance with 3.1.
Unless otherwise specified (see 6.2), first article inspection shall consist
of the examination in 4.6 and all tests in 4.7. The machine shall pass the
examination and all tests to be accepted.
4.5 Quality conformance inspection. Quality conformance inspection shall
be applied to each item prior to being offered for acceptance under the
specified
(see 6.2), quality conformance
Unless otherwise
contract.
inspection shall consist of the examination in 4.6, the tests in 4.7, and the
inspection in 4.8. The machine shall pass the examination, all tests, and the
.
inspection to be accepted.
4.6 Examination. The machine shall be examined to determine compliance
with all requirements of this specification.
4.7 Tests.
4.7.1 Test conditions. All tests shall be performed in an indoor facility
with ambient conditions of
to
Fahrenheit (F), and 20 percent to
95 percent relative humidity.
4.7.2 Operational test. Each machine shall be operated at no load for not
less than 30 minutes. Proper operation of all controls, motors, adjusting
mechanisms, and accessories shall be verified during the trial period.
4.7.3 Performance tests. The grooving machine shall be tested to determine
compliance with 3.5. Complete grooving operations shall be performed on the
type steel workplaces of not less than 50,000 P.S.I., tensile strength. The
resulting seams, inside and outside, shall be smooth and firmly folded along
All performance tests shall be completed without making
their entire length.
any adjustments to or performing any maintenance on the machine.
4.8 Packaging inspection.
Packaging of each item shall be inspected to
determine compliance with the requirements of section 5.
PACKAGING
5.
5.1 Packaging requirements.
The requirements
for packaging shall be in
accordance with MIL-M-18058.
